22-33GHz WR-34 WAVEGUIDE MAGIC T

Product Categories

HeFei Vinncom Electronic Technology Co.,Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: 2233GHz WR34 WAVEGUIDE MAGIC T
Brand: Vinncom
Price: 1 USD

Model Number : VN-WGMT-2233-WR34

Operating Frequency ( GHz ) : 22-33

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 500

Brand Name : Vinncom

Part Number : VN-WGMT-2233-WR34

MOQ : 5 pcs

Symmetry(dB) : ±0.4

Place of Origin : China

VSWR E-plane : 1.5:1(Typical surfance)

Price : negotiable

Isolation(dB) : ≥30

Certification : ISO 9000 ROHS

Insertion Loss(dB) : 1.3:1(Typical surfance)

Contact Now

22-33GHz WR-34 WAVEGUIDE MAGIC T

Power combiners and dividers –
A WAVEGUIDE MAGIC T equally splits a high‑power signal into two paths, or combines two signals into one.
alanced mixers –
A WAVEGUIDE MAGIC T combines the local oscillator (LO) signal and the RF signal in an image‑rejection mixer architecture.
Phase comparators and detectors –
A WAVEGUIDE MAGIC T compares the phase difference between two input signals at the collinear ports.
Connect source to H‑arm –
For in‑phase power division, feed the input signal into the H‑arm of the WAVEGUIDE MAGIC T.
Use collinear arms as outputs –
The two collinear arms of a WAVEGUIDE MAGIC T serve as balanced outputs, each receiving half the input power.
